Outdoor PIR Motion Sensor TD-R37

Specification:

Working voltage: DC 9v to 16v
Working current: 30mA
Detection distance: 8m*8m
Detection angle: Wide Angle 90 degree
Mounting: wall mounted
Mounting height: 2.1m~2.7m
Detection unit: Dual PIR
Pet Immune: 20KG
Environment humidity: ≤95%RH(no condensation)
Alarm output Dry Contact: Signal NC NO
Waterproof grade: IP65
Microwave frequency: 10.525CHZ
Application: Outdoor
Size: 176*85*69mm

Features:

1. 100% waterproof with IP65 certificate
2. With fireproof material case
3. LED on/off optional
4. Ant-tamper function
5. Integrating the most advanced security technology
6. Wired Double Passive Infrared Detector with high accuracy,intelligent digital chip,make an accurate judgment of true intruder or other interference that can cause wrong alarm
7. And it is with function of automatic memory of environmental change
8. Prevent effectively the interference caused by a 20 kg past or 10 cats, insect, mouse, birds etc.

9. Detection Coverage:8m*8m wide angle 90 degree
